Codeline 96000 Head Seal

Kami adalah importir distributor agen dan supplier Codeline 96000 Head Seal terlengkap menyediakan berbagai kebutuhan spare part filter untuk keperluan industri dengan price harga terbaik

CodeLine membrane housings are built to maximize the performance of your water purification systems. For over 3 decades, CodeLine Fiberglass pressure vessels have been used in critical & demanding applications Desalination, Reverse Osmosis, Nanofiltration & Ultrafiltration.

CodeLine 80S30 membrane Head Seal housing part

99218 SHELL
Filament Wound Epoxy/Glass composite - Head locking grooves integrally wound in place.
2 A/R A/R F/C Port SA-351 CF3M
3 A/R A/R F/C Port Seal Ethylene Propylene.
4 2 194448 Bearing Plate Assembly -
4.1 1 96156 Bearing Plate SB-221 A96061-T6
4.2 1 97105 Danger Label -
5 2 96160 Sealing Plate Engineering Thermoplastic.
6 2 96162 Permeate Port Engineering Thermoplastic.
7 2 45066 Port Nut Engineering Thermoplastic.
8 2 96000 Head Seal Ethylene Propylene - O - Ring
9 2 45312 Perm Port Seal Ethylene Propylene - O - Ring
10 2 47336 Quick Release Spiral Ring SA-479 316
11 2+ 52169 Saddle Engineering Thermoplastic.
12 2+ 45042 Strap Assy. 304 Stainless Steel-PVC Cushion.
13 4++ 46265 Strap screw. 5/16-18 UNC, 2.5''-L,18-8 Stainless Steel.
14 2 A/R Adapter Engineering Thermoplastic.
15 2 52245 Adapter seal Ethylene Propylene - O - Ring
16 4 A/R PWT Seal Ethylene Propylene - O - Ring
17 1 96163 Thrust Cone Engineering Thermoplastic.
+3 & ++6 each furnished with length code 4,5,6,7 & 8

CodeLine 80S100 membrane housing part

99220 SHELL
Filament Wound Epoxy/Glass composite - Head locking grooves integrally wound in place.
2 A/R A/R F/C Port SA-995 ( UNS J93380) CD3MWCuN
3 A/R A/R F/C Port Seal Ethylene Propylene
4 2 194454 Bearing Plate Assembly -
4.1 1 96158 Bearing Plate SB-221 A96061-T6
4.2 1 96168 Danger Label -
5 2 96160 Sealing Plate Engineering Thermoplastic.
6 2 96162 Permeate Port Engineering Thermoplastic.
7 2 45066 Port Nut Engineering Thermoplastic.
8 2 96000 Head Seal Ethylene Propylene - O - Ring
9 2 45312 Perm Port Seal Ethylene Propylene - O - Ring
10 2 47336 Quick Release Spiral Ring SA-479 316
11 2+ 52169 Saddle Engineering Thermoplastic.
12 2+ 45042 Strap Assy. 304 Stainless Steel-PVC Cushion.
13 4++ 46265 Strap screw. 5/16-18 UNC,2.5''- L,18-8 Stainless
Steel.
14 2 A/R Adapter Engineering Thermoplastic.
15 2 52245 Adapter seal Ethylene Propylene - O - Ring
16 4 A/R PWT Seal Ethylene Propylene - O - Ring
