ROPV R8040B300S-6

Kami adalah importir distributor agen dan supplier ROPV R8040B300S-6 Housing RO Membrane FRP terlengkap menyediakan berbagai kebutuhan spare part filter untuk keperluan industry dengan price harga terbaik.

Info lengkap Housing RO Membrane

Description ROPV Housing RO Membrane FRP
ROPV pressure vessel is designed to withstand 6 times the designed pressure before a catastrophic failure occurs. As a safety precaution the housings are designed for a full body leak at 4 times the design pressure to keep catastrophic failure from happening. Each standard vessel is carefully inspected and a hydro‐test is performed to ensure its reliability before delivering from the plant.
ROPV Pressure Vessels are designed to provide safe operation over a long service life if properly installed, operated, and maintained. The vessel may cause loss of life, severe bodily harm, or property damage if improperly installed, operated, or maintained. Read and understand all guidelines provided in the vessel User Manual. Observe every precaution contained therein. Failure to do so may result in malfunction and potential catastrophic failure. It is recommended that only qualified technicians experienced in servicing hydraulic systems work with this vessel. Misuse, incorrect assembly, or use of damaged/corroded components may result in catastrophic failure.

Specification ROPV

8inch Side Port FRP Membrane Housing 600PSI

Side Port Size: 1.5’, 2’, 2.5’ clamp available

Permeate port: 1’ NPT

Port material: SS2205/SS2507

Length: (1-7) x 40inch

Designed pressure: 600PSI (41bar)

Pressure vessel for 8inch RO, NF and UF membranes.

Key Features

Operating Temp Range: -10°C --49°C (14°F-120°F)

Pressure test:  Standard--- 1.1x Design Pressure,  ASME--- 1.5x Design Pressure

Internal permeate port not to exceed 125PSI(0.88MPa)

Operating pH Range: 3 – 11

Cleaning pH Range: 2 – 12 (less than 30 minutes)

Please operate in accordance with User Guide

Untuk informasi lebih lanjut tentang produk dan penawaran harga ROPV R8040B300S-6 Housing RO Membrane FRP silahkan hubungi kantor kami.
